Growatt MID 30KTL3-X
$1,560
Description
A three-phase grid-tied solar inverter with a 30 kilowatt (kW) maximum AC power output, the MID-30KTL3-X. Large-scale commercial and industrial solar arrays are intended for it.
Here are some of the main characteristics and details of the Growatt MID 30KTL3-X:
- 30 kW is the maximum AC power output.
- 33 kW is the maximum DC power input.
- 200-1000 V MPPT Voltage Range
- A 99% maximum efficiency
- There are 2 MPP Trackers.
- Switches for Integrated DC: Yes
- Available GPRS/Ethernet, WiFi, and RS485 communication interfaces
- Monitoring and Control: Compatible with Growatt's monitoring platform and mobile app for remote monitoring and control.
- Grid Support Functions: Includes reactive power control, power factor control, and low voltage ride-through capability.
- Compact Design: Lightweight and compact design for easier installation.
Other features of Growatt MID 30KTL3-X
- High efficiency: Growatt inverters are renowned for their high efficiency, which contributes to maximizing the amount of electricity generated by solar panels.
- Multiple MPPTs: Most Growatt inverters contain multiple maximum power point detectors (MPPTs), enabling flexible installation and optimum operation under various shading circumstances.
- Broad Input Voltage Range: Inverters frequently offer a broad input voltage range, enabling them to function well with various solar panel types and configurations.
- Built-in WiFi or Ethernet connectivity: Many Growatt inverters have WiFi or Ethernet connectivity, enabling consumers to remotely monitor and manage their solar system via a specialized monitoring platform or mobile app.
- LCD: Growatt inverters often incorporate a user-friendly LCD that shows operating data in real-time, including output power, energy production, and system condition.
6. Growatt inverters frequently feature lightweight, compact designs that simplify installation and use.
- Safety Features: Growatt inverters often have safety features like over-voltage, over-current, short-circuit, and temperature protection to guarantee secure and dependable functioning.
To get the most accurate and latest information about growatt inverter in dubai, it is recommended to visit igrowattinverter website or contact us directly.
Additional information
| Brand |
Growatt |
|---|---|
| Inverters type |
On Grid Inverters |
| watt |
21000W ~ 40000W |
1 review for Growatt MID 30KTL3-X
Input Data (PV)
| Max. recommended PV power (for module STC) |
45000W |
| Max. DC voltage | 1100V |
| Start voltage | 250V |
| Nominal voltage | 600V |
| MPPT voltage range | 200-1000V |
| No. of MPP trackers | 3 |
| No. of PV strings per MPP tracker | 2 |
| Max.input current per MPP tracker | 26A |
| Max. short-circuit current per MPP tracker |
32A |
Output Data (AC)
| AC nominal power | 33000W |
| Max. AC apparent power | 33300VA |
| Nominal AC voltage(range*) | 220V/380V, 230V/400V (340-440V) |
| AC grid frequency;(range*) | 50/60 Hz (45-55Hz/55-65 Hz) |
| Max. output current | 50.5A |
| Adjustable power factor | 0.8leading…0.8lagging |
| THDi | <3% |
| AC grid connection type | 3W+N+PE |
Efficiency
| MAX. efficiency | 98.8% |
| European efficiency | 98.5% |
| MPPT efficiency | 99.9% |
Protection devices
| DC reverse polarity protection | Yes |
| DC Switch | Yes |
| AC/DC surge protection | Type II / Type II |
| Insulation resistance monitoring | Yes |
| Ground fault monitoring | Yes |
| Grid monitoring | Yes |
| Anti-islanding protection | Yes |
| Residual-current monitoring unit | Yes |
| String monitoring | Yes |
| AFCI protection | Optional |
General data
| Dimensions (W / H / D) | 525/395/222mm |
| Weight | 29.5kg |
| Operating temperature range | –25 °C ... +60 °C |
| Self-Consumption (night) | < 1W |
| Topology | Transformerless |
| Cooling | Smart air cooling |
| Protection degree | IP66 |
| Relative humidity | 0~100% |
| Altitude | 4000m |
| DC connection | H4/MC4(Optional) |
| AC connection | Cable gland+OT terminal |
| Display | OLED+LED/WIFI+APP |
| Interfaces: Interfaces: RS485 / USB / WiFi/ GPRS / RF/ LAN |
Yes/Yes /Optional/Optional/Optional/Optional |
| Warranty: 5 years / 10 years
|
Yes/Optional |
| CE, VDE0126, Greece, EN50549, C10/C11, UTE C 15-712, IEC62116,IEC61727, IEC 60068, IEC 61683, CEI0-21, CEI0-16, N4105, TOR Erzeuger, G98/G99, G100, AS/NZS 3100, AS4777, UNE217001, UNE206007, PO12.2, KSC8565 |
|
| * The AC voltage range and frequency range may vary depending on specific country grid standard. All specifications are subject to change without notice. |
|
