Growatt Hope 5 kwhr
$700
| Datasheet | SPF 2000TL HVM-24 | SPF 3000TL HVM-24 | SPF 2000TL HVM-48 | SPF 3000TL HVM-48 | SPF 5000TL HVM/HVM-P |
| Battery Voltage | 24VDC | 48VDC | |||
| Battery Type | Lithium/Lead-acid | ||||
| INVERTER OUTPUT | |||||
| Rated Power | 2000VA/ 2000W | 3000VA/ 3000W | 2000VA/ 2000W | 3000VA/ 3000W | 5000VA/ 5000W |
| Parallel Capability | No | No/ Yes，6 units maximum | |||
| AC Voltage Regulation (Battery Mode) | 230VAC ± 5%
@ 50/60Hz |
||||
| Surge Power | 4000VA | 6000VA | 4000VA | 6000VA | 10000VA |
| Efficiency (Peak) | 93% | ||||
| Waveform | Pure sine wave | ||||
| Transfer Time |
10ms typical, 20ms Max |
||||
| SOLAR CHARGER | |||||
| Maximum PV Array Power | 1500W | 1800W | 4500W | ||
| MPPT Range @ Operating Voltage | 30VDC ~ 80VDC | 60VDC ~ 115VDC | |||
| Maximum PV Array Open Circuit Voltage |
102VDC |
145VDC |
|||
| Number of Independent MPP Trackers/ Strings Per MPP Tracker | 1/1 | ||||
| Maximum Solar Charge Current | 50A | 30A | 80A | ||
| Maximum Efficiency | 98% | ||||
| AC CHARGER | |||||
| Charge Current | 30A | 15A | 60A | ||
| AC Input Voltage | 230 VAC | ||||
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | ||||
| Frequency Range | 50Hz/60Hz (Auto sensing) | ||||
| PHYSICAL | |||||
| Protection Degree | IP20 | ||||
| Dimension (W/H/D) | 315/400/130mm | 350/455/130mm | |||
| Net Weight (kgs) | 8 | 8.5 | 8 | 8.5 | 11.5 |
| OPERATING ENVIRONMENT | |||||
| Humidity |
5% to 95% Relative Humidity(Non-condensing) |
||||
| Altitude | <2000m | ||||
| Operating Temperature | 0°C - 55°C | ||||
| Storage Temperature | -15°C - 60°C | ||||
